MTRJ-SC OM1 Duplex Patch Lead

• Tweet

FO-MTRJSC | MTRJ-SC 62.5-125 OM1 Multi Mode Duplex Fibre Optic Patch Lead

	Average ETA for Additional Units	Discontinued
	Product Datasheet	Download

High quality, multi-purpose Fibre Patch Cable for your mission-critical installation.

Highest specification OM1 laser optimised multi mode cable designed for 10Gb Ethernet (250 metres at 1Gb down to 30 metres at 10Gb), but suitable for both LED and VCSEL laser light sources. Recommended for internal connections within cabinets between fibre patch panels and switches where 62.5/125 OM1 Multi Mode cable has been used in the infrastructure.

• RoHS Compliant
• LSZH (Low Smoke Zero Halogen) PVC jacket.
• Fibre Connectors are Machine UPC (Ultra Polished Connectors)
• 1 x MTRJ connector
• 2 x SC Connectors
• UL Approved with high quality corning fibres
• Ceramic ferrules
• Typical insertion loss of less than 0.5dB
• Factory manufactured and fully tested
• Fibre cable is Multimode Duplex, core thickness is 62.5 microns, with an outside cladding of 125 microns
• OM1 rated
