Powered CAT5 VGA Baluns with Audio

Product Selection Menu

For stock availability and product enquiries.

AC-1671 | Powered CAT5 VGA Baluns with Audio extension up to 300M - Digitech

Average ETA for Additional Units  1-2 Days
Product Datasheet Download

Powered CAT5 VGA Baluns with Audio

Able to transmit VGA and audio signals across a standard UTP or STP Cat-5 cable for distances up to 300 metres. Adjust the brightness and skew of the image with the peak and gain options.

Use for home or commercial applications, for example, classrooms, lecture halls, auditoriums, retail kiosks, video information displays, trade shows, etc. Ideal for VGA monitors or LCD projection screens. Supports up to 1920 x 1200 pixels. Supplied as a sender and receiver pair with plug packs included.

Specifications:
  • Power requirements: 5VDC for both sender and receiver
  • Sender Dimensions: 100(L) x 65(W) x 26(H)mm
  • Receiver Dimensions: 81(L) x 43(W) x 23(H)mm
  • Vertical frequency range: 60/75/85Hz
  • Supported resolutions: 640X480, 800X600, 1024X768, 1280X720, 1280X768, 1280X960, 1280X1024, 1600X900, 1600X1200, 1920X1080, 1920X1200
  • Includes 2 x right angle mounting brackets for send unit
