Megapixel HD Wireless N PTZ Internet Camera

Product Selection Menu

TV-IP672W | Megapixel HD Wireless N Pan/Tilt/Zoom Network Camera - TRENDnet Networking Products

Average ETA for Additional Units  Contact Us
Product Datasheet Download

The Megapixel HD Wireless N PTZ Internet Camera, model TVIP672W, provides video monitoring over a large area. Pan the camera side-to-side a remarkable 340° and tilt up-and-down 115° from any Internet connection. Wireless n technology provides unsurpassed wireless coverage and improved streaming video quality. Add this camera to your wireless network at the touch of a button with Wi-Fi Protected Setup (WPS).

Record 1280 x 800 Megapixel (WXGA) video at up to 30 frames per second (fps). Manage up to four video profiles to record HD video while streaming low resolution video to a compatible smart phone at the same time. Manage up to 32 TRENDnet cameras with the included complimentary camera management software. Advanced features include adjustable motion detection recording areas, email alerts, scheduled recording sessions, pan / tilt, Auto-Patrol, H.264 / MPEG-4 / MJPEG image compression, date-and-time overlays, a Micro-SD card slot for backup storage, two-way audio (speakers not included), an adjustable lens, and four times digital zoom. A wall / ceiling mounting kit is included and the camera's off white housing blends into most environments.

  • Wi-Fi compliant with IEEE 802.11n standard
  • Backwards compatible with IEEE 802.11g and IEEE 802.11b devices
  • One touch WPS connection button
  • 1 x 10/100 Mbps Auto-MDIX RJ-45 port (for optional wired connection)
  • Power and activity LED indicators (can be disabled)
  • 2-way audio: built-in microphone and audio out port for third party speakers
  • 4x digital zoom
  • Micro SD card slot*
  • Manual focus lens
  • Stream and record up to 4 different video profiles simultaneously
  • Pan left or right 170° for a total of 340°
  • Tilt the camera up 90° and down 25° for a total of 115°
  • Stream Network camera video to a 3GPP compatible wireless device
  • Dynamic DNS support
  • Supports up to 1280 x 800 pixel resolution at up to 30 frames per second
  • Image controls: brightness, contrast, auto gain control, noise reduction, saturation, sharpness, back light control, hue, frequency, flip image vertically, mirror image horizontally, and black and white mode
  • Event Trigger: motion detection or digital input signal
  • Event Action: send real-time snapshots (up to 3 before and 3 after the event) or video recording (up to 5 seconds before and 10 seconds after the event) to FTP or email
  • Samba client support to record to a NAS drive
  • Supports TCP/IP networking, email, HTTP, Samba and other Internet protocols
  • System controls:
    • Define up to 20 user login accounts
    • Set the date and time or synchronize with an NTP server
  • Supports wireless encryption up to WPA2-PSK
  • Quick Universal Plug and Play (UPnP) installation
  • Mounting base and mounting hardware included

    *Micro SD card sold separately.

      Part Number Product Description
      TV-IP672W Megapixel HD Wireless N Pan/Tilt/Zoom Network Camera
